GAP

GAP is a multiphase oil and gas optimiser tool that models the surface gathering network of field production systems. When linked with the well models of PROSPER and reservoir models of MBA La full field production optimisation and forecast can be achieved. GAP can model production systems containing oil, gas and condensate, in addition to gas or water injection systems.

GAP's powerful non-linear optimisation engine allocates gas for gas lifted wells or sets wellhead chokes for naturally flowing wells to maximise revenue or oil/gas production while honouring constraints at any level in the system.

Multi-well optimisation for artificially lifted and naturally flowing production networks:

  • Surface gathering system models with constraints
  • Looped networks
  • Gas and condensate gathering systems
  • Oil and water gathering systems
  • Injections networks
  • Compressor modelling
  • Pump modelling

Optimisation of gathering system against constraints:

  • Fast and robust Global Optimisation algorithm using non-linear programming (NLP) which has been recognised in the industry as best in class.
  • Wellhead chokes can be set, compressors and pumps optimised, and gas for gas lifted wells allocated to maximise production
  • Multiple Flowlines
  • Multiple Separators
  • Unlimited number of nodes - wells, reservoir, etc.
  • Field optimisation studies with mixed systems (ESP, GL, Naturally Flowing, PCP, Jet and Rod Pumps)
  • Optimise production forecasting

Pipeline Flow Assurance Studies

Reservoir Management

  • Models injection system performance, using MBAL or other numerical reservoir models
  • Advises on wellhead chokes settings to meet reservoir management targets

Fully Compositional from the Reservoir to the Process side
Easy to use graphical interface for drawing system network (using icons for separators, compressors, pipelines, manifolds and wells, inline chokes and reservoir tanks)

Case Examples Paper from Oman



Integrated Production and Injection Networks

Petex was created in 1990 with the objective of providing best in class software that would allow various disciplines to perform studies in understanding the behaviour of fields as well as design systems and optimise production. GAP was designed to eliminate artificial boundary conditions in reservoir, well and surface network models, through the creation of integrated models using Petex tools. It is able to consider the multiphase network response of multiple wells (with different PVT) producing into a common production system, where the response of one well would affect production of another (i.e. back pressure response). Today GAP is the most sophisticated steady state multiphase network optimiser that exists in the industry, with many proprietary features that allow engineers to maximise production from oil and gas fields all over the world. GAP has been the tool of choice for over 420 oil companies in over 80 countries and the corporate standard for all of the super majors in the area of integrated modelling. Year on year new features are added and improvements are made based on the development strategy of Petex and the requests from clients presented at the user meeting.

Equations Based Solver

The objective of GAP is to capture the full field response of a hydrocarbon field using physical descriptions of each item that will affect production. The fundamental calculations done in GAP relate to balancing pressure, flow and temperature from all items in a system based on a single boundary condition at the end point (for production networks) or starting point (for injection networks). The solver being used is an equation-based proprietary engine that has been specifically designed and built for solving integrated oilfield networks. Starting points are internally evaluated and decades of research have allowed this to be the fastest network solver in the industry today (independently verified in tests by various oil companies). The solver takes into account all the physics that are present in the system and works by drawing information from all parts of the system, by performing dynamic calculations on the physical models (for pipelines, chokes, wells, compressors etc), or by using pre-calculated responses (for example lift curves).

Non-Linear Optimisation

Once physical models are in place as an integrated system, optimisation algorithms can be used with the objective of increasing hydrocarbon recovery. For the past 20 years, one of the biggest areas of research in Petex has been on a mathematically rigorous global non-linear optimisation algorithm that is proprietar y and unique in the industry. The user does not have to provide starting points and intelligence built into the system allows for selecting the appropriate technique depending on the problem at hand. Local optimisation techniques like BFGS, Fletcher Reeves, Rank1 and various others are nested within the structure of the optimiser and are coupled with a proprietary global optimum search engine that searches the whole production and injection space for the best possible solution. The control settings that will satisfy constraints as well as maximise production are then presented to the user in the form of choke settings, artificial lift quantities, compressor speed and any other control that may exist in the field and has been allowed to be considered in the optimisation problem.

Rule Based Constraints

GAP is often used for long term planning activities and for testing various strategies through long term forecasting. The objective in this context is not to optimise production on a day to day basis, but rather to honour constraints and evaluate long term production goals. This is achieved by using the Rule Based Network Solver functionality. The model is setup in the same way as it is to achieve optimisation objectives, the difference being in the fact that the constraints are met through a set of well defined rules that are adjusted by the user depending on the problem at hand. As this algorithm is extremely fast, forecasts can be obtained quickly and can include artificial lift individual well production maximisation (equal slope techniques for gas lifted wells for example).

Well Performance

The performance of wells is typically handled by embedding PROSPER models in the integrated system, although dynamic well models can be captured through native GAP calculations. Wells can therefore be evaluated and optimised over time with respect to the back pressure response of the entire network. Design and performance can be assessed through the life span of each well, considering artificial lift (pumps, gas lift, etc.) or any other type of intervention. Flow assurance analysis features very strongly in well modelling, with dynamic calculations as well extended lift curves being used to assess the safe flowing envelopes that pressures, temperatures and rates will allow. Diagnostics of any proposed/existing design and how it handles future production conditions are at the centre of evaluation workflows in the tool.

Flow Assurance

Flow assurance studies centre around the detection of specific phenomena that are a function of the fluid PVT or the pipeline hydraulics (e.g. Slugging, Liquid loading, Wax formation, Hydrate formation, etc.). GAP harnesses all the existing functionality from PVTp and PROSPER to detect these phenomena across the entire surface network, and provide information that will address flow assurance challenges over time. Moreover, workflows can be setup in RESOLVE so that all the native functionality in GAP can be used as part of a bigger solution formulation scheme, going as far as performing calculations in real time for any objective the client wishes to embed in support of their field management activities.

Advanced PVT Handling

GAP has been designed to be able to handle different PVT descriptions that are used in the reservoir, wells and surface network. For instance, a fully compositional reservoir simulator will typically contain no more than 6-8 components, and everything downstream of this will usually contain more. GAP can use the lumped composition, and perform the delumping to a larger component composition. The Black Oil to Compositional feature in GAP was created to enhance the performance of these integrated models. This was achieved by using the EOS to generate the inputs of Black oil model, and using both descriptions in tandem. The consequence is a fluid description that harnesses all the advantages of EOS and black oil descriptions, without any of the weaknesses. © Petroleum Experts Ltd. 2015

Unconventionals

GAP TECHNICAL CAPABILITIES

GAP is often used for long term recover y estimates and testing the intended field. In recent years the production of unconventional reservoirs has become more viable and as such the need to capture the inflows, system response and PVT of coal bed methane (CBM), tight, shale and heavy oil reservoirs has increased. GAP has extended its functionality into this domain, allow the dewatering cycles and production cycles of CBM to be captured. The tight reservoir and shale inflow response is captured in REVEAL, but the multiphase flow in the well, and surface network is analysed in GAP.

Surface Equipment Modelling

As exploration focuses on more remote inaccessible locations, long trunklines to transport fluids back to processing facilities are common place as are the use of various turbo-machiner y to supplement the production efforts. In GAP compressors (single and tandem screw compressors, reciprocating and multiphase) and pumps (per formance cur ves, jet pumps and bespoke multiphase) can all be modelled. Their response in time as production conditions change can also be assessed, thus making GAP an invaluable design tool in this context.
